自動化雙面去毛刺+噴淋清洗防銹烘干

自動化雙面去毛刺+噴淋清洗防銹烘干

Application Scope:

Metal stamping, machining, grinding machine processing, powder metallurgy and other workpiece double-sided polishing deburring, chamfering, rust removal, de-oxidation, cleaning and drying, rust prevention, etc.

Service Hotline:

400-8282-811

Enquire Now


Parameters Principle Diagram Applications Video
Main Function Features

1. The whole line can complete all processes in turn, such as automatic loading, double-sided precision polishing and deburring, cleaning and drying, rust prevention, and automatic receiving. Each minute can process 60--100 pieces of various valve plates, friction plates, thrusters, spacers and other workpieces; assembly line through the type of operation, modular combination, customers according to the demand of the whole purchase or optional related modules.


2. The whole set of equipment is the world's first automatic double-sided polishing, cleaning and drying production line special equipment, Wanchuang has completely independent intellectual property rights, has authorized the whole invention patent and software copyright certification.


3. The excellent structure function of the equipment ensures the super durability, safety and stability of the equipment; the equipment is energy efficient, convenient in operation and simple in maintenance, and the technical functions are far ahead of similar equipment at home and abroad, which is widely recognized by the market and unanimously praised by users, and is the first choice of the relevant industries.


Product Parameters

Scope Of Application: Metal stamping, machining, grinding machine processing, powder metallurgy and other workpieces double-sided polishing deburring, chamfering, rust removal, removal of oxide skin, cleaning and drying, rust prevention, etc.

Processing Range: Length, width (20-300mm), thickness (0.2-50mm).

The Whole Line Configuration And Process Flow: Automatic loading (optional) - front polishing and deburring (optional single or multi-station) - automatic turning - back polishing and deburring (optional single or multi-station) - demagnetization - degreasing and cleaning (optional ultrasonic or water spray) - water spray rinsing (optional multi-station, cleaning water with water-based rust inhibitor can prevent rust) - wind cutting water - hot air circulation drying - automatic receiving (optional) Note: If oil-based antirust is required, the antirust process will be completed after drying. Equipment support customization

Rated Power: 32-45KW.

Total Weight (approx.): 6T.

Appearance Size (length, width and height): 10000-12000*1200mm*2300.

Control System: Human-machine interface, PLC programming control, one-touch start-stop equipment.

Power Supply Voltage: Three-phase five-wire, 380V, 50HZ.

相關標簽:去毛刺

Are you still looking for fully automatic polishing, grinding and deburring integration equipment?
